PTFE / Teflon Bellow Mechanical Seals

PTFE / Teflon Bellow Mechanical Seals Bellow Seals

Chemically inert PTFE and GFT (Glass Filled PTFE) bellow seals for handling strong acids, alkalis, and oxidizing agents. Available in GFT and RCF bellow types with SS clamp construction. Covers 20mm to 120mm shafts from -30°C to 250°C.

Specifications

Size20–120 mm
Temperature−30 °C to 250 °C
Pressure8 kg/cm²

Materials of Construction

Seal FacesGFT, Carbon, Silicon, TC, Ceramic, SS
Metal PartsSS304, SS316, SS316L

Available Variants (2)

Specifications as listed in the FLUID PROOF product catalogue.

Select a variant

Teflon Bellow (GFT) Unbalanced Seal

Teflon Bellow (GFT) Unbalanced Seal

Seal Size
20 mm to 120 mm
Pressure
8 kg/cm²
Speed
12 m/s
Temperature
−30 °C to 250 °C
Rotary FaceGFT
Stationary SeatSilicon, TC, SS, Ceramic
Seat TypeT-Type, S-9
Secondary SealsPTFE, GFT
Metal PartsSS304, SS316, SS316L
ApplicationAcids, Alkalies, Strong Oxidising
